Laptop Lenovo Legion 5

SKU: 83NXX000R1Temporarily UnavailableCertified Refurbished

$1,732.15

Save 32.9% ($848.45)$2,580.6

Temporarily Unavailable

Price history

Intel Core Ultra 9 275HX Processor (E-cores up to 4.60 GHz P-cores up to 5.40 GHz)
32 GB DDR5-5600MT/s (SODIMM)(2 x 16 GB)
1 TB SSD M.2 2242 PCIe Gen4 TLC
16" WQXGA (2560 x 1600), IPS, Anti-Glare, Non-Touch, HDR 400, 100%DCI-P3, 500 nits, 240Hz, Low Blue Light
80 Wh

Processor

Processor: Intel Core Ultra 9 275HX Processor (E-cores up to 4.60 GHz P-cores up to 5.40 GHz)
Operating System: Windows 11 Home 64
Cache: 36MB Intel® Smart Cache
Cores / Threads: 24 (8 P-core + 16 E-core) / 24
NPU: Intel® AI Boost, up to 13 TOPS
Overall TOPS: Up to 36 TOPS

Memory

Storage

Storage: 1 TB SSD M.2 2242 PCIe Gen4 TLC
Max Storage Support: Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB each
Storage Slot: Two M.2 2280 PCIe® 4.0 x4 slots

Graphics

Display

Display: 16" IPS
Resolution: 2560x1600
Aspect Ratio: 16:10
Screen-to-Body Ratio: 91.7% AAR (active area ratio)
Contrast Ratio: 1200:1
Viewing Angle: 89° / 89° / 89° / 89°
Certified: DisplayHDR™ 400, Dolby Vision®, NVIDIA® G-SYNC®, Advanced Optimus, TÜV Rheinland® Low Blue Light, TÜV Rheinland® High Gaming Performance
Color Calibration: X-Rite® factory color calibration

Battery

Connectivity

Physical

Weight: 2.43kg / 5.35lbs
Color: Storm Grey
Condition: Certified Refurbished
Warranty: 1 Year Standard Depot Warranty
Part Number: 83NXX000R1
Case Material: Aluminium (top), PC-ABS (bottom)
Dimensions (WxDxH): 364.38 x 268.06 x 21.69-25.95 mm (14.35 x 10.55 x 0.85-1.02 inches)
Pen: No support
Touchpad: Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Surface Treatment: Anodizing sandblasting
System Lighting: No system lighting

Platform

Chipset: Intel® HM870 chipset
Audio Chip: High Definition (HD) Audio, Realtek® ALC3306 codec
Speakers: Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio
Microphone: Dual-microphone array
Card Reader: No card reader
Docking: Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for Legion 5 16IAX10
Monitor Support: Supports up to 4 independent displays (native display and 3 external monitors via HDMI® and USB-C®) • HDMI® supports up to 7680x4320@60Hz • USB-C® supports up to 7680x4320@30Hz
NPU: Integrated Intel® AI Boost, up to 13 TOPS
Max Battery Life: MobileMark® 30@250nits: 4.3 hr Local video (1080p) playback@150nits: 8.2 hr
Special Features: AI Chip: LA3
Temperature: At altitudes up to 2438 m (8,000 ft) - Operating: 5°C to 35°C (41°F to 95°F) - Storage: 5°C to 43°C (41°F to 109°F)
Altitude: Maximum altitude (without pressurization): 3048 m (10,000 ft)

Ports

USB-A: 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
USB-A: 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
USB-C: 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort™ 2.1
Thunderbolt / USB-C: 1x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with DisplayPort™ 2.1
HDMI: 1x HDMI® 2.1, up to 8K/60Hz
Audio Jack: 1x Headphone / microphone combo jack (3.5mm)
Ethernet: 1x Ethernet (RJ-45)
Standard Ports: 1x Slim tip Power connector

Security

Durability & Certifications

Platform

AI PC Category: AI-Powered Gaming PC or AI PC
Relative Humidity: Operating: 8% to 95% at wet-bulb temperature 23°C (73°F) or Storage: 5% to 95% at wet-bulb temperature 27°C (81°F)

Reference data from Lenovo's official spec sheet for this model line. May not reflect this exact unit's configuration. View full spec sheet
